TML - CALORIFIER (OR) STORAGE TANK

Overview :

PRODUCTS FOR DOMESTIC HOT WATER

AISI316L STAINLESS STEEL

Our best-selling products which have contributed to build TML's reputation and reliability. Thanks to our 40-year experience, we are leader for the production of equipments made of chromium-nickel-molybdenum austenitic chrome AISI 316L (1.4404) stainless steel with very low level of carbon.

After being carefully manufactured with a high level of automation, calori- fiers and thermal stores are subject to a temperature monitored pickling chemical treatment and then passivated.

They are available with fixed coils or with removable heat exchangers work­ing with water or steam.

Standard capacities from 150 to 5000 litres.

GLASS LINED CARBON STEEL

The most cost-effective solution: cylinders are made of S 235 Jr carbon steel with a glass lining protection, suitable to be used in contact with domestic water at high temperatures (up to 95 °C).

They are available with fixed coils or with removable heat exchangers working with water or steam.

Standard capacities from 150 to 2000 litres.

KERAMTECH LINED CARBON STEEL

Mainly used for big capacities (above 2000 litres), the cylinder is made of S 235 Jr carbon steel coated with a ceramic lining, suitable to be used in contact with domestic water at high temperatures (up to 100 °C). They are available with removable heat exchangers working with water or steam.

Standard capacities from 2000 to 5000 litres.

PRODUCTS FOR PRIMARY WATER

PAINTED MILD STEEL, GALVANIZED MILD STEEL, AISI 304 STAINLESS STEEL

They are used for heating and cooling applications in circuits working without oxygen.
They can also be equipped with auxiliary coils or with heat exchangers for instantaneous production of domestic hot water.

  • Carbon steel (for buffer vessels, heating and cooling stores, combined buffer stores)
  • Galvanized carbon steel (for chilled water buffer stores)
  • AISI 304 stainless steel (hot and chilled water buffer stores)

NO. CAPACITY MODEL TYPE
1 200 - 1000L ELV - ELECTRICAL CALORIFIER GLASS LINED
2 200 - 1000L ELX - ELECTRICAL CALORIFIER STAINLESS STEEL
3 150 - 5000L ATX - ELECTRICAL CALORIFIER STAINLESS STEEL
4 150 - 5000L SFI & DSFI - HOT WATER TANK STAINLESS STEEL (FIXED COIL)
5 150 - 2000L SFV & DSFV - HOT WATER TANK GLASS LINED (FIXED COIL)
6 200 - 2000L BV1V - HOT WATER TANK GLASS LINED (1 REMOVABLE COIL)
7 2000- 5000L BV1K - HOT WATER TANK KERAMTECH (1 REMOVABLE COIL)
8 200 - 5000L BV1X - HOT WATER TANK STAINLESS STEEL (1 REMOVABLE COIL)
9 200 - 2000L BV2V - HOT WATER TANK GLASS LINED (2 REMOVABLE COIL)
10 2000- 5000L BV2K - HOT WATER TANK KERAMTECH (2 REMOVABLE COIL)
11 200 - 5000L BV2X - HOT WATER TANK STAINLESS STEEL (2 REMOVABLE COIL)
MODEL CATALOGUE
ELV - ELECTRICAL CALORIFIER Download
ELX - ELECTRICAL CALORIFIER Download
ATX - ELECTRICAL CALORIFIER Download
SFI & DSFI - HOT WATER TANK Download
SFV & DSFV - HOT WATER TANK Download
BV1V - HOT WATER TANK Download
BV1K - HOT WATER TANK Download
BV1X - HOT WATER TANK Download
BV2V - HOT WATER TANK Download
BV2K - HOT WATER TANK Download
BV2X - HOT WATER TANK Download
